Ametek 116669-50 Vacuum Motor - 2-Stage Blower, 5.7 in. Frame, 120 V
Brand:
Mfr. Model #:
116669-50
KR Part #:
VAL6669-50
Weight:
4.20 lbs
(1)Single-speed, two stage electric thru-flow vacuum motor. 120 V operation, capable of moving up to 94.0 CFM. Specially designed for moving clean and dry air - perfect for your car wash vacuum systems.
Prop 65
120 Volts
Technical Specifications
CFM: 94
Voltage AC: 120
Amps: 7.7
Phase: 2
Product Description
94.0 CFM Thru-Flow Motor
Compact - 5.7 inches in diameter - the Ametek 116669-50 vacuum motor is an excellent choice for thru-flow vacuum needs. Aluminum fan end bracket and commutator bracket combines light weight with sturdiness. Designed to handle clean, dry, filtered air only. Perfect for use with commercial canister and utility vacuum units, sprayers, foggers, and any other central vacuum system at your car wash or auto shop!
Features
- Two-stage motor
- Skeleton-frame design
- Ball/sleeve bearings
- UL recognized, category PRGY2 (E47185)
Specifications
- Max CFM: 94 CFM
- Max Amps: 7.7 Amps
- Max Voltage: 120 VAC
- Vacuum Rating: 90.2
- Max Ambient Temperature: 40 degC
